| For Chuck Size... (Inch/mm) | F (mm) | A (mm) | B (mm) | C (mm) | Morse Taper | T | a (mm) | b (mm) | c (mm) | h (mm) | t # of Bolts x Size |
| 6 / 160 | 140 | 125 | 20 | 3.5 | 3 | M10 | 10 | 15 | 6 | 12 | 4 x M8 |
- Fully machined for fixturing and mounting 2, 3 or 4-jaw lathe chucks onto rotary tables, etc.
- High carbon steel
- Precision ground for accuracy
